H Frame Box Type Power Press Machine
The H Frame Box Type Power Press Machine is engineered for high-precision and heavy-duty metal forming operations such as punching, blanking, bending, stamping, and pressing.
Its box-type H-frame construction offers exceptional rigidity, balanced load distribution, and minimal deflection, ensuring stable and accurate performance under continuous high-load conditions.
The enclosed frame design enhances safety, reduces vibration, and improves die life, resulting in consistent and uniform output.
Manufactured using heavy-grade materials and precision-engineered component, this machine delivers smooth operation, reliable performance, and long service life.
Suitable for demanding industrial applications, the H Frame Box Type Power Press Machine is widely used in automotive components, sheet metal fabrication, electrical parts manufacturing, and general engineering industries.
H Frame Box Type Power Press Machine
The H Frame Box Type Power Press Machine is engineered for high-precision and heavy-duty metal forming operations such as punching, blanking, bending, stamping, and pressing.
Its box-type H-frame construction offers exceptional rigidity, balanced load distribution, and minimal deflection, ensuring stable and accurate performance under continuous high-load conditions.
The enclosed frame design enhances safety, reduces vibration, and improves die life, resulting in consistent and uniform output.
Manufactured using heavy-grade materials and precision-engineered component, this machine delivers smooth operation, reliable performance, and long service life.
Suitable for demanding industrial applications, the H Frame Box Type Power Press Machine is widely used in automotive components, sheet metal fabrication, electrical parts manufacturing, and general engineering industries.
Product Specification
Capacity: - 10 ton to 500 tons.
Frame: - Made from MS steel plates. Full steel body presses.
Clutch:- MS
Shaft:- EN/8
Clutch KEY:- WPS
Connecting ROD: MS
BED: MS
RAM: Graded C.I
Load Wheel: Graded C.I
Main Gear: MS Fabricated.
Pinion Gears: MS. Made from solid steel bars.
Gear teeth: Helical types.
Gun metal bushes: Graded along with test certificates.
Gun metal brass: Fitted in connecting ROD.
Brake: C.I & MS.
Standard Accessories:
Flywheel & Gear Guards
Oil Cups
Lubrication System - Oil Pump.
Motor Pulley
Knockout System
Slide Adj. Spanner
A Pair of Die Clamp
Extra Clutch Key (For 50 Ton & above)
Optional Accessories:
Pneumatic Clutch with Photo Safety Sensors
Two Hand-Operated Push Buttons.
Auto Lubrication System
Electrical Motor, Starter & V-Belt
Stroke Counter
Extra Base Plate
Inclinable Fixed & Adjustable.
Anti-vibration mount
